Bulk Storage

The TranStore® intermediate bulk container is the most advanced liquid handling tank in the market today.

Intermediate Bulk Containers (IBC)

An intermediate bulk container, or IBC, is a type of reusable container made for the storage and transport of bulk liquids. These containers are highly utilized in the food, chemical, petroleum and pharmaceutical industries, and come in a wide variety of sizes and shapes to accommodate different industry needs. IBCs typically have a stacking design and can be moved with a pallet jack or forklift. If you are looking for a high-quality IBC that is custom built for the type of processing you do most, look no further than Custom Metalcraft’s TranStore line of IBCs. Not only do we have the technology required to manufacture IBCs of all shapes and sizes, we have the experience needed to suit your individual needs. Our design team can solve virtually any storage and transportation problem you might have, and is available by phone or email to address all of your questions and concerns.

STANDARD INTERMEDIATE BULK CONTAINER FEATURES
  • One-piece sloped bottom assures uniform and complete drainage
  • 1/4″ thick combination lifting lugs for offshore and domestic applications
  • 10 gauge stainless steel IBC construction with 2B finish (if applicable)
  • 22-1/2” diameter top fill opening with removable drum cover
  • Pressure relieving and venting device
  • EPDM gasket with plated clamp ring
  • Stackable up to four IBC containers high, dependent upon tank size and surrounding conditions
  • One-piece stamped valve guard
  • 2″ top bung opening
  • 2″ stainless steel ball valve (if applicable)
  • Tank mounted operating instructions and warning labels
  • Near limitless service life with minimal maintenance
With a one-piece top and superior draining bottom, TranStore IBC containers set the industry standard for performance. Prior to ship, the interior and exterior are cleaned using the automated “TransClean” system. TranStore IBCs provide nearly limitless service life with minimal maintenance.
Heavy duty 1/4” thick lifting lugs & stacking positioners
Heavy duty formed tank legs
Standard drum cover with 3” fusible vent / fill cap, bolted clamp ring and 2” bung
Stackable
STANDARD SIZES
TranStore Metal IBC Standard Sizes
All dimensions are approximate. Tanks may bulge slightly when full.
